100pcs Soviet KD510A Silicon Si Pulse Diode 50V 200mA
100pcs Soviet KD510A Silicon Si Pulse Diode 50V 200mA
Regular price
€8,33 EUR
Regular price
Sale price
€8,33 EUR
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
100pcs Soviet KD510A Silicon Si Pulse Diode 50V 200mA
KD510A (КД510А)
TECHNICAL DATA
:
Reverse voltage, maximum: 50 V
Reverse voltage (pulse), maximum: 70 V
Forward current, maximum: 200 mA
Forward current (pulse) , maximum: 1 500 mA
Reverse current: 0.005 mA
Reverse recovery time: 4 ns
Working temperature, o C: -60 to +125
Diameter: 1.5 mm
Body length: 4.4 mm
Weight: 0.2 g
----------------------------------------------------------------------------------------------------------------------------------------------------
Combine shipping is accepted.
If you need less or more items of this type, or if you need add some other items, contact us, and we will make special listing for you.
Give us the list of items you need, and we'll do the rest.
We have many other vacuum tubes for audio and other, ask us if you need any of them.
Items are shipped from Lithuania Post (Europe Union) via expedited International tracking.
Returns
We guarantee you complete satisfaction with all our high quality products.
If you receive an item you did not order, or if an item you ordered is received damaged or defective, we will refund you the price you paid for it or replace it with identical one.
The item should come to the above address within 30 days after you received it.
After 30 days we will no longer be responsible and the item won't be taken back.
Item for returning must have the original tags and packing, otherwise it won't be accepted.
